Motorola XPR 7580e Radio


Price:
Add to cart or Log In to view price

Description

The Motorola XPR 7580e radio is a 1000 channel handheld unit that is ideal for public safety, oil and gas, mining, and manufacturing industries. The XPR 7580e transmits using digital 800/900 MHz frequencies.

Thinking about upgrading to the XPR7580e from a Motorola XPR6000 series radio?

View a PDF detailing the differences between the two generations.

Motorola XPR7580e radio highlights

  • Digital and analog transmissions
  • 1000 channels
  • 800 and 900 MHz frequency bands
  • 2.5 watts max power out
  • Full color display w/full keypad
  • Orange dedicated emergency button
  • Intrinsically safe option (UL) available
  • 5 year Motorola warranty

Model numbers

800/900 MHz Capable - AAH56UCN9WB1AN
800/900 MHz Enabled - AAH56UCN9RB1AN

Battery life

    The XPR 7580e radio has a max power output of 2.5 watts which exhausts the standard Li-Ion battery PMNN4491 in ~21 hours.

    If you need more battery life, there is an optional high capacity Li-ion battery, PMNN4493, which bumps the operating time up to ~28 hours.

    Motorola XPR7580e range

    The baseline XPR 7580e range using the standard 800/900 MHz antenna is:

    Flat open terrain

    2 - 3 miles

    Suburban areas 1 - 2 miles
    Urban areas 1 - 2 miles
    Inside buildings

    30 - 40 floors

    These are averages based on the Motorola XPR 7580e radio using standard accessories at full power. There are many factors that affect two-way radio range, and it is always best to test before you invest.

    Supported system technologies

    • Conventional analog/digital
    • IP site connect
    • Capacity plus
    • Linked capacity plus
    • Connect plus (enabled version)
    • Capacity max (enabled version)
    • Wave OnCloud

    Similar Motorola digital radios

    If you aren't sure if the XPR 7580e radio is the right fit, check out our other Motorola digital radios.

    Recommended alternatives

      Free Motorola XPR 7580e radio programming with purchase

      Motorola XPR 7580e accessories

      Shop Motorola XPR 7580e radio accessories

      Downloads and Resources

      XPR 7580e Radio Specifications

      Channel Capacity
      1000
      Programmable buttons
      Yes, 5 buttons
      User programmable?
      No, requires dealer support
      DurabilityIP68 Waterproof
      Mil spec: 810 D, 810 E

      Performance data

      Frequency range800 MHz (806-825/851-870 MHz)
      900 MHz (896-902/935-941 MHz)
      Max Power output2.5 Watts
      Coverage areaAdjustable power output for varying coverage
      Repeater capableYes
      Estimated battery life19 hours (Capable)
      28 hours (Enabled)
      Capable batteryPMNN4491 Li-ion
      Capable battery size2100 mAh
      Enabled batteryPMNN4493 Li-ion
      Enabled battery size3000 mAh

      Physical specifications


      Dimensions (H x W x D)
      5.1 x 2.2 x 1.4 in.
      Weight w/capable battery11 oz.
      Weight w/enabled battery12 oz.
      DisplayYes, full color
      KeypadYes, full keypad
      Emergency buttonYes
